Clipol Combination Switch Socket is of a surface switch and a socket outlet in a PC mounting box. There are many options available to suit your needs. Specially designed for industrial infrastructures. All products comply with Australian Standards.
| Iterm | Socket switch durable industrial 5 pin 20 amp color electrical sockets and switches |
| Model | Waterproof Switch And Sockets -C66CV520 |
| Material | Polycarbonate |
| Type | Combination switched sockets, standard grounding |
| Color | White |
| Voltage | 500V |
| Current | 20A |
| Pin No. | 5 |
| IP Rating | IP56 |
| Feature |
1. Max Vol: 250 ~ 500V Rated Current: 10 ~ 63A Pin Type: 3 ~ 5 Pins 2. UV resistance, insulating, fireproof |
| Standard | AS/NZS 3123 |
| Warranty | 10 years |
| Certificate | SAA |
| Market | Australia, New Zealand, Fiji, etc. |
| Usage | Industrial, construction site, laboratory application etc. |
| Reference Model | ||||
|
Item Code |
Volts |
Amp |
Pin No. |
IP Rating |
|
C66CV310 |
250V |
10A |
3 |
IP56 |
|
C66CV315 |
250V |
15A |
3 |
IP56 |
|
C66CV320 |
500V |
20A |
3 |
IP56 |
|
C66CV332 |
500V |
32A |
3 |
IP56 |
|
C66CV410 |
500V |
10A |
4 |
IP56 |
|
C66CV420 |
500V |
20A |
4 |
IP56 |
|
C66CV432 |
500V |
32A |
4 |
IP56 |
|
C66CV440 |
500V |
40A |
4 |
IP56 |
|
C66CV450 |
500V |
50A |
4 |
IP56 |
|
C66CV510 |
500V |
10A |
5 |
IP56 |
|
C66CV520 |
500V |
20A |
5 |
IP56 |
|
C66CV532 |
500V |
32A |
5 |
IP56 |
|
C66CV540 |
500V |
40A |
5 |
IP56 |
|
C66CV550 |
500V |
50A |
5 |
IP56 |
