Clipol Combination Switch Socket is of a surface switch and a socket outlet in a PC mounting box. There are many options available to suit your needs. Specially designed for industrial infrastructures. All products comply with Australian Standards.
1. Max Vol: 250 ~ 500V Rated Current: 10 ~ 63A Pin Type: 3 ~ 5 Pins
2. UV resistance, insulating, fireproof
Item Code
Volts
Amp
Pin No.
IP Rating
C66CV310
250V
10A
3
IP56
C66CV315
250V
15A
3
IP56
C66CV320
500V
20A
3
IP56
C66CV332
500V
32A
3
IP56
C66CV410
500V
10A
4
IP56
C66CV420
500V
20A
4
IP56
C66CV432
500V
32A
4
IP56
C66CV440
500V
40A
4
IP56
C66CV450
500V
50A
4
IP56
C66CV510
500V
10A
5
IP56
C66CV520
500V
20A
5
IP56
C66CV532
500V
32A
5
IP56
C66CV540
500V
40A
5
IP56
C66CV550
500V
50A
5
IP56
Iterm
Switch and socket waterproof for Industrial, OEM PC IP56 5 pin 10 amp switch socket
Model
Waterproof Switch And Sockets -C66CV510
Material
Polycarbonate
Type
Combination switched sockets, standard grounding
Color
White
Voltage
500V
Current
10A
Pin No.
5
IP Rating
IP56
Feature
Standard
AS/NZS 3123
Warranty
10 years
Certificate
SAA
Market
Australia, New Zealand, Fiji, etc.
Usage
Industrial, construction site, laboratory application etc.
Reference Model
